Advantages of the solar street light 100 watt: By utilizing monocrystalline silicon photovoltaic panels combined with gallium nitride LED chips, the system achieves a luminous efficacy of 180 lm/W, halving power consumption while doubling brightness. Over a ten-year period, total costs are reduced by 59% compared with 200W sodium lamps, delivering significant benefits in carbon emission reduction and light pollution control.
Certifications: ISO 9001, ISO 14001, ISO 45001, CE, IEC, RoHS, TÜV, FCC, CCC, CB, UN 38.3, MSDS, IK08, EN 40, LM-79, TM-21
Parameter
| Model NO. | GD-40 | GD-60 | GD-80 | GD-100 | GD-120 | GD-150 |
| Lamp Power | 40W | 60W | 80W | 100W | 120W | 150W |
| Solar Panel | 80W | 100W | 120W | 150W | 180W | 210W |
| Lithium Battery | 384WH | 460WH | 614WH | 768WH | 922WH | 1228WH |
| LED Quantity | 48pcs*2 module | 48pcs*2 module | 48pcs*2 module | 48pcs*3 module | 48pcs*3 module | 48pcs*4 module |
| Luminous Flux | 8000lm | 11400lm | 16000lm | 20000lm | 22800lm | 28500lm |
| CCT | 3000-6500K | |||||
| CRI | >70Ra | |||||
| Charging Time | 4-6 hours | |||||
| Working Time | 3-5 rainy days | |||||
| Working Temperature | -20℃~75℃ | |||||
| Lifespan Material |
≥80000hours Die-casting Aluminum |
|||||
| IP Rating | IP66 | |||||
| Case Diameter | 60mm | |||||
| Mounting Height | 6-8m | 6-8m | 8-12m 10-12m | 10-15m | 10-15m | |
| Mounting Distance | 25-35m | 25-35m | 25-40m 30-40m | 30-40m | 30-50m | |
The solar street light 100 watt employs triple protection-Class II double insulation, IP66 protection, and safety extra-low voltage (SELV)-effectively eliminating the risk of electric shock.
Class II Double Insulation
Primary Insulation: A 1.5 mm-thick flame-retardant PC housing (4,000 V dielectric withstand voltage) isolates the LED driver from the lamp post;
Secondary Insulation: An additional 0.8 mm-thick silicone sleeve (2,000 V dielectric withstand voltage) forms a dual protective barrier over the primary insulation;
Test Standard: Complies with IEC 60598-1 and passes the 1,500 V high-voltage withstand test for 1 minute without breakdown;
IP66 Protection Rating
Dustproof: Completely prevents dust ingress (IP6X), avoiding short circuits caused by conductive dust accumulation;
Waterproof: Withstands high-pressure water jets (IPX6), preventing rainwater from penetrating live components.
Safety Voltage Design
Solar Power Supply: System operating voltage ≤ 60 V DC (approximately one-quarter of mains voltage), ensuring no risk of lethal electric current upon human contact;
Overvoltage Protection: Built-in TVS diodes clamp the voltage to within 72 V, effectively suppressing surges caused by lightning strikes or battery overcharging.
Production workshop
Solar Street Light Projects
Certificate
FAQ
Q: How to connect solar street light 100 watt?
A: Installing solar street light 100 watt is extremely straightforward. First, our solar street lights 100 watt feature an integrated design. Before leaving the factory, the solar panel, light fixture, lithium battery, and controller are fully assembled and internally wired into a single unit. During installation, customers only need to prepare the concrete foundation in advance. The solar street light is then mounted onto the top of the light pole and securely fastened with screws. Finally, a crane is used to erect the light pole and firmly anchor it to the foundation.
