1. Product Introduction
Municipal LED street lighting refers to the street lamp that made with LED light source. It has the unique advantages of high efficiency, safety, energy saving, environmental protection, long life, fast response, high color rendering index, and is of great significance for energy saving of urban lighting. LED light source, which is powered by low-voltage DC, is composed of GaN-based power blue LED and yellow high-efficiency white light. Municipal LED street lighting can be widely used in roads. The outer cover can be made with high temperature resistance up to 135 degrees and low temperature resistance up to - 45 degrees.
2. Product Parameter (specification) of the municipal led street lighting
Parameters of LED lamp
|
Part Number |
GD-L1802 |
GD-L1803 |
GD-L1804 |
GD-L1805 |
GD-L1806 |
|
Wattage |
100W |
150W |
200W |
250W |
300W |
|
Lumen Output |
15000-16000lm |
22500-24000lm |
30000-32000lm |
37500-40000lm |
45000-48000lm |
|
Luminous Efficacy |
150-160lm/W |
155-160lm/W |
155-160lm/W |
155-160lm/W |
155-160lm/W |
|
Input Voltage |
90-305V AC/200-240V AC 50-60Hz |
||||
|
CCT |
2800~6500K |
||||
|
CRI |
≥70 or ≥80 or ≥90 |
||||
|
IP & IK Rating |
IP66&IK10 |
||||
|
Surge protection |
Line earth 4KV, Line-line 10KV/20KV available |
||||
|
Power factor |
>0.95 |
||||
|
Power efficiency |
90% |
90% |
90% |
90% |
|
|
THD |
<15% |
||||
|
Working temperature |
-40℃~50℃ 20%~90% H.R |
||||
|
Storage temperature |
-40℃~85℃ 10%~90% H.R |
||||
|
Light pole size |
Ø60mm |
||||
|
Housing material |
AL6063-T5 |
||||
|
Housing color |
Black or grey |
||||
|
Insulation |
Class 2 |
||||
|
Options |
PWM /DALI/1-10V/Timming/Daylight sensor/Nema 7 Pin socket |
||||
|
Lifespan |
>50,000Hrs |
||||
Parameters of Street Light pole
|
Material |
Q235 Steel |
|
Type |
Octagonal or Conical |
|
Height |
3-15M |
|
Galvanizing |
Hot dip galvanized (average 100 micron) |
|
Powder Coating |
Customized powder coating color |
|
Wind Resistance |
Designed to with stand wind speed of 160km/hr |
|
Life Span |
＞20 years |
Parameters of Anchor Bolt
|
Material |
Q235 Steel |
|
Bolts and Nuts Material |
Stainless Steel |
|
Galvanizing |
Cold dip galvanized process ( optional ) |
|
Features |
Detachable, helping to save transport space and cost |
The above configuration is only for reference and the actual configuration is designed according to the local climate conditions and the customer special requirements.
3. Product feature and application
Uniform color of our products: in the absence of lenses, uniform colors are sacrificed in order to increase brightness, thus ensuring uniform color without aperture, as well as small light decay, less than 3% in one year, and still meet road requirements after 10 years of use; Our Municipal LED Street Lighting have automatic control of energy-saving devices that can minimize power, save electricity and meet lighting requirements at different times. It can realize computer dimming, time control, lighting control, temperature control, automatic detection and other humanized functions.
What's more, Our Municipal LED Street Lighting have a long life span of more than 50,000 hours as well as offering a three-year warranty. More importantly, our products have a unique secondary optical design that illuminates the street light to the desired lighting area, further improving lighting efficiency and thus achieving energy savings.
4. Production details
5. Production process
6. Delivery, Shipping and Serving
7. FAQ:
Q1: Are you a manufacturer or a trade company?
A: We are a Manufacturer with more than 10 years experience
Q2: How can I get the samples?
A: We'll appreciate it if you can pay the cost and freight of samples.
Sample needs 5-7 days, mass production time needs 2-3 weeks for order quantity more than
Q3: How much is the transportation freight of the samples?
A: The freight depends on the weight and packing size, as well as the place or port of destination.
Q4: How to make a payment?
A: We can accept the payment by L/C, T/T, Western Union or PayPal. Please tell us the payment that you prefer, we will send the detail information to you.
Q5: How do your factory control quality?
A: Quality is the most important part for us.
In order to control quality better, we have professional QC. All our products pass 4 times inspection by QC before delivery. The first is raw material, second for finished products, third for products appearance and fourth for function.
